| Features | 1.Three variations of head phantoms with different features for arteries to meet your requirements: CT/ Angiography / Multi energy CT / 2. Contrast-enhanced left cerebral arteries are three dimensionally embedded in the brain |
|---|---|
| Training skills / Applications | CT/ Angiography / Multi energy CT |
| Set includes | 1 head phantom / 1 storage case / 1 set of sample X-ray data (DVD) / manual |
| Size (approx.) | H33cm / 13in |
| Packing size (approx.) | W46 x D31 x H32cm / W18.1 x D12.2 x H12.6in |
| Weight (approx.) | 5.25kg / 11.57lb |
| Packing weight (approx.) | 8kg / 17.6lb |
| Materials | Soft tissue: urethane based resin / Cervical vertebrae (C1-C7): epoxy resin |
| Anatomy | A synthetic skull / Soft tissue / Simulated arteries with contrast medium / Left anterior cerebral arteries / Left middle cerebral arteries / Internal carotid artery / Diameters of simulated0.5-4.0 mm / *Arrangement of arteries are the same for all three types. |
| HU | Soft tissue 0 / Cerebrum 40 / Mesencephalon 40 / Cerebellum 40 / Cerebral ventricles 10 / Eye balls 20 |
| Update | July 20, 2020 |
